Medscribe AI Backend

This repository contains the audio transcription backend for Medscribe AI, an AI medical scribe that records doctor-patient conversations, transcribes them, and generates structured follow-up summaries.

The backend is a Dockerized FastAPI service hosted on Hugging Face Spaces. It accepts audio uploads, improves audio quality with a denoising and normalization pipeline, sends the processed audio to Groq Whisper, and returns a typed JSON transcription response to the Next.js frontend.

Demo Video: YouTube walkthrough

Related Links

• Backend Space: huggingface.co/spaces/zeyadcode/medscribe-backend
• Production API: zeyadcode-medscribe-backend.hf.space
• Frontend App: medscribe-ai-lilac.vercel.app/dashboard
• Frontend Repository: zeyad-shaban/medscribe-ai-frontend
• Backend Repository: zeyad-shaban/medscribe-ai-backend
• Demo Video: YouTube walkthrough

Screenshots

Add backend screenshots or diagrams to docs/assets/ using these filenames. The README is already wired to render them once the files are added.

API Docs	Hugging Face Space

Audio Pipeline	CI/CD

What It Does

• Exposes a FastAPI /transcribe endpoint for audio upload.
• Loads uploaded audio with librosa.
• Applies DeepFilterNet denoising before transcription.
• Normalizes RMS level and protects against clipping.
• Resamples audio to 16 kHz for the Groq transcription API.
• Sends cleaned audio to whisper-large-v3-turbo through Groq.
• Returns a Pydantic-validated JSON response with transcript text, filename, and duration.
• Runs as a Docker container on Hugging Face Spaces.
• Uses GitHub Actions to sync the repository to Hugging Face Hub after pushes to main.

Engineering Highlights

• Production-style API boundary between the web app and transcription service.
• Audio preprocessing pipeline designed to improve transcription quality before calling the speech-to-text model.
• Containerized deployment with a Hugging Face-compatible Dockerfile and port configuration.
• Typed response schema with Pydantic for predictable frontend integration.
• CI/CD workflow that pushes backend updates from GitHub to Hugging Face Hub.
• Built as part of a solo full-stack AI project covering frontend, backend, AI orchestration, deployment, and infrastructure.

Architecture

flowchart LR
    Frontend[Next.js Frontend] --> Upload[POST /transcribe]
    Upload --> FastAPI[FastAPI Service]
    FastAPI --> Decode[librosa Audio Decode]
    Decode --> Denoise[DeepFilterNet Denoising]
    Denoise --> Normalize[RMS and Peak Normalization]
    Normalize --> Resample[Resample to 16 kHz]
    Resample --> Groq[Groq Whisper large-v3-turbo]
    Groq --> Response[Pydantic TranscriptionResponse]
    Response --> Frontend

Tech Stack

Area	Technology
API framework	FastAPI
Runtime	Python 3.10
Data validation	Pydantic
Audio loading/resampling	librosa, scipy
Audio denoising	DeepFilterNet
ML/audio runtime	PyTorch, torchaudio
Speech-to-text	Groq Whisper whisper-large-v3-turbo
Deployment	Docker on Hugging Face Spaces
CI/CD	GitHub Actions, huggingface/hub-sync

API Reference

Health Check

GET /

Response:

{
  "status": "ok"
}

Transcribe Audio

POST /transcribe
Content-Type: multipart/form-data

Form field:

Name	Type	Description
file	audio file	Audio conversation file to clean and transcribe.

Example response:

{
  "transcript": "Patient reported...",
  "filename": "consultation.wav",
  "duration_seconds": 42.7
}

Local Development

Prerequisites

• Python 3.10
• ffmpeg
• Groq API key

Setup

python -m venv .venv
.venv\Scripts\activate
pip install -r requirements.txt
uvicorn app:app --reload --host 127.0.0.1 --port 8000

On macOS/Linux, activate the virtual environment with:

source .venv/bin/activate

Create .env.local:

GROQ_SECRET_KEY=

Open http://127.0.0.1:8000/docs to test the FastAPI endpoint.

Docker

Build and run locally:

docker build -t medscribe-ai-backend .
docker run --env-file .env.local -p 7860:7860 medscribe-ai-backend

The container listens on port 7860, which is the expected port for Hugging Face Spaces Docker apps.

CI/CD

The repository includes a GitHub Actions workflow at .github/workflows/sync-to-hub.yml.

On every push to main, the workflow:

1. Checks out the repository.
2. Enables Git LFS support.
3. Pushes the backend code to the Hugging Face Space using huggingface/hub-sync.

Required GitHub secret:

HF_TOKEN=

Project Structure

.
  app.py
  Dockerfile
  requirements.txt
  config/
    constants.py
    settings.py
  schemas/
    transcription.py
  utils/
    audio_cleaning.py
  notebooks/
    eda.ipynb
    deepfilternet_demo.ipynb
  .github/
    workflows/
      sync-to-hub.yml

Roadmap

• Add speaker separation before or after transcription.
• Add automated tests before syncing to Hugging Face.
• Host more AI model logic directly on Hugging Face.
• Add automatic model switching and fallback behavior during API spikes.
• Expand observability around transcription latency and failure modes.

Clinical Safety Scope

Medscribe AI is built as an AI-assisted documentation workflow. The backend provides transcription support for clinician review and should not be treated as a medical device or official medical record system by itself.
